i5A-907 LED Receiving Card

Click Here to Get Factroy Price LED Display and LED Modules

Colorlight i5A-907 Dual Mode LED Display Receiving Card, LED Control System receiving Card, Synchronous LED Display Control System.

i5A-907 mini led card is specially designed for the compact and portable LED displays, such as LED color display and casting aluminum cabinet. It has mini size and inherits all the advantages and features as i receiver series such as colorlight i5A/i5A-F/i5A-905 have.higher refresh rate, better led display effect, more stable screen, higher gray level output, higher level of color input, and more delicate images; better uniformity and more gorgeous color at low gray level;

PRODUCT FEATURES

1: with Mini size
2: Large load capacity
3: most suitable for the compact structure designs ,such as color screen and casting aluminum cabinet
4: Advanced design, high quality components, rigorous aging test, zero malfunction of final products
5: Compatible with iT7, iQ7, iQ7E,gigabit NIC, etc.
6: Supports in Brightness and chromaticity calibration
7: Support normal chip, PWM, lighting chip
8: High refresh rate, high gray scale and high brightness
9: Better detail processing: Partial dark at row, reddish at low gray, shadow problems can be solved.
10: Support various freeform display, spherical display, diamond display, creative display, etc
11: Support signal output for 16 groups of RGBR’ and 24groups of RGB
12: Support any scan mode from static to 1/32 scan
13: Power supply from pin board without the need of external power supply
14: Wide working voltage range with DC3.3 -6V
