| Product Category | Switch Power Supply |
| Manufacturer | MEAN WELL |
| Product | Switching Supplies |
| Output Voltage-Channel 1: | 5 VDC |
| Number of Outputs: | 1 Output |
| Output Power | 300 W |
| Open Frame/Enclosed: | Enclosed |
| Input Voltage | 90 VAC to 132 VAC, 180 VAC to 264 VAC Selectable, 254 VDC to 370VDC |
| Ouput Current-Channel 1: | 60 A |
| Industry: | Commercial |
| Isolation Voltage: | 3 kVAC |
| Mounting Style: | Chassis |
| Length: | 215 mm |
| Witdh:1 | 115 mm |
| Height: | 30 mm |
| Approvals: | UL60950-1 |
| Series: | NEL-400 |
| Brand: | MEAN WELL |
| Input Frequency: | 47 Hz to 63 Hz |
| Load Regulation: | Regulated |
| Unit Weight: | 2.204 lbs |
•AC input range selectable by switch
•Protections: Short circuit / Overload / Over voltage/
Over temperature
•Cooling by free air convection
•Withstand 300vac surge input for 5 second
•Built-in constant current limiting circuit
•100% full load burn-in test
•LED indicator for power on
•Fixed switching frequency at 90KHz
•Low cost，high reliability
