| Product Category | Switch Power Supply |
| Manufacturer | MEAN WELL |
| Product | Switching Supplies |
| Output Voltage-Channel 1: | 5 VDC |
| Number of Outputs: | 1 Output |
| Output Power | 400 W |
| Open Frame/Enclosed: | Enclosed |
| Input Voltage | 180 VAC to 264 VAC, 254 VDC to 370 VDC |
| Ouput Current-Channel 1: | 80 A |
| Industry: | Commercial |
| Isolation Voltage: | 3 kVAC |
| Mounting Style: | Chassis |
| Length: | 215 mm |
| Witdh:1 | 115 mm |
| Height: | 30 mm |
| Approvals: | UL60950-1 |
| Series: | NEL-400 |
| Brand: | MEAN WELL |
| Input Frequency: | 47 Hz to 63 Hz |
| Load Regulation: | Regulated |
| Unit Weight: | 1.164 lbs |
• AC input 180-264VAC
• Protections: Sho内circuitl Overload I Over voltagel ver temperature
• Leakage current<1mA
• Forced air cooling by built-in DC fan
• Low profile:30mm
• Withstand 300vac surge input for 5 second
• LED indicator for power on
• Conformal ∞ating
• Low cost，high reliability
• 100% fullload burn-in test
